Original FG-40F FortiGate-40F Network Firewall 40xGE-RJ45 Port

Hardware Specifications

• Dimensions: Width: 8.5 in, Depth: 5.5 in, Height: 1.4 in.
• Weight: 1 kg.
• Ports: 3 x 1000base-t - RJ-45, 1 x FortiLink - RJ-45, 1 x 1000base-t - RJ-45 (WAN/DMZ), 1 x Console - RJ-45, 1 x USB 3.0 - Type A.
• Form Factor: Desktop.
• Power: External power adapter, Voltage required: AC 120/230 V (50 - 60 Hz), Power consumption operational: 16.6 watt.

System Performance

• IPS Throughput: 1 Gbps.
• NGFW Throughput: 800 Mbps.
• Threat Protection Throughput: 600 Mbps.
• Firewall Throughput (1518-byte UDP): 5 Gbps.
• Firewall Throughput (512-byte UDP): 5 Gbps.
• Firewall Throughput (64-byte UDP): 5 Gbps.
• Firewall Throughput: 7.5 Mpps.
• VPN Throughput (512-bit IPsec): 4.4 Gbps.
• VPN Throughput (SSL): 490 Mbps.
• SSL Inspection Throughput: 310 Mbps.
• SSL Inspection Throughput (connections per second): 320.
• Application Control (HTTP 64k): 990 Mbps.
• Concurrent Sessions: 700,000.
• New Sessions: 35,000.
• Firewall Policies: 5,000.
• Gateway to Gateway IPsec VPN Tunnels: 200.
• Client to Gateway IPsec VPN Tunnels: 250.
• Concurrent SSL VPN Users: 200.
• SSL Inspection Concurrent Sessions: 55,000.

Other Specifications

• Virtual Domains: 10.
• Number of FortiSwitches: 8.
• Number of FortiAP Devices: 10.
• Number of FortiAP Devices (Tunnel Mode): 8.
• Number of FortiToken Devices: 500.
• Number of Registered FortiClients: 20,000.
• Latency: 4 µs.
• Operating Temperature: Min operating temperature: 0 °C, Max operating temperature: 40 °C.
• Humidity Range: 10 - 90 % (non-condensing).
• Compliant Standards: UL, VCCI, C-tick, CUL, CB, FCC Part 15 Class B, ICSA IPsec Certified, ICSA Firewall Certified, ICSA Antivirus, ICSA SSL-VPN, ICSA IPS.
• Encryption Algorithm: SSL, TLS 1.3.
• Processor: 1 x Fortinet Forti ASIC SOC 4
