Private Mold R940XA 4U Rack Server Super Computing Power System with Four-socket Processor

private mold : Yes

products status : Stock

type : Rack

processor main frequency : Servers

processor type : Servers

brand name : /

model number : R940XA

place of origin : Shanghai, China

Product name : Servers

MOQ : 1PCS

Warranty : 1year

Lead Time : 1-3 Working Days

Package : Original Packaging

MOQ : 2 pieces

Price : CN¥16,606.46/pieces >=2 pieces

Contact Now

Product Description

Private Mold R940XA 4U Rack Server Super Computing Power System with Four-socket Processor

Specification

Product Description

Product Name	R940 SERVER
Processor	Up to four 2nd generation In tel Scalable processors, up to 28 cores per processor.
Storage controllers Internal guidance	Internal controller: PERC H330, H730P, H740P, HBA330 External controller: H840, 12 Gbps SAS HBA, HBA355e Software RAID: S140 Boot Optimized Storage Subsystem (BOSS)：HWRAID 2 x M.2 SSD 240 GB、480 GB Internal dual SD module 1.
Drive bay	Front drive carrier: Up to eight 2.5 "SAS SATA (HDD/SSD), up to 61.44 TB or up to 24 2.5" SAS/SATA (HDD/SSD), up to 184.32 TB Or up to 32 SAS/SATA (HDD/SSD), up to 4 NVME PCIe SSDs, up to 245.76 TB.
Power supply	Gold 1100 W - 48 VDC Platinum: 1100W, 1100W 240 VDC2 1600W、2000W、2400W Hot swap power supply with full redundancy option 6 hot swappable fans with N+1 redundancy.
Sizing	Outline specification: rack (4U) Height: 174.3 mm (6.87 ") Width: 441.16 mm (17.37 ") Depth: 835.9 mm (32.9 ") Weight: 56.0 kg (123.5 lb).
Memory	48 DDR4 DIMM sockets, support for RDIMM/LRDIMMs, up to 2933 MT/s, up to 6 TB Up to 12 NVDIMMs, up to 384 GB – Up to 24 Intel ® Aoteng ™ Permanent memory PMem, 12.28 TB maximum (15.36 TB maximum with PMem+LRDIMMs) Only registered ECC DDR4 DIMMs are supported.
Embedded / At-Server	iDRAC9 iDRAC Direct.
I/O & Ports	Network Daughter Card Options 4 x 1 GbE, 4 x 10 GbE, 2 x 10 GbE+2 x 1 GbE or 2 x 25 GbE Front port: 1 x dedicated iDRAC direct Micro-USB、2 x USB 2.0、1 x VGA。 (Optional 1 x USB 3.0 is only available on 8 Provided on the drive configuration) Rear port: 1 x dedicated iDRAC network port, 1 x serial, 2 x USB 3.0 1 x VGA Built in port: 1 USB 3.0 Video card: 2 VGA PCIe: Up to 12 x 3.0 slots (6x16 slots or 2x16+10x8 slots).
GPU	Up to 4 double wide GPUs or up to 4 double wide Or 8 single width full height FPGAs.
Supported Operations system	Canonical® Ubuntu® LTS Citrix® Hypervisor Oracle® Linux with Hyper-V Microsoft Windows Server® LTSC Red Hat® Enterprise LinuxSUSE® Linux Enterprise Server VMware® ESXi
Weight	Gross weight: 46.9 kg.
