Customized EX3400 Series Ethernet Network Switch with Private Mold and Customized Size 24 Ports

Product Categories

Shanghai Apying Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

private mold : NO

products status : Stock

ports : 24

transmission rate : 10/100/1000Mbps

function : LACP, POE, QoS, SNMP

communication mode : Full-Duplex & Half-Duplex

switch capacity : /

brand name : /

model number : EX3400

place of origin : Shanghai, China

Size : Customized Size

Color : Customizable

Suitable for : Workstation, Laptop, Desktop

Price : CN¥5,924.83/pieces 1-1 pieces

Contact Now

Product Description

Description	EX3400 24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Form factor	Fixed platform Virtual Chassis configuration consisting of up to 10 switches Junos Fusion Enterprise Satellite device
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit
Backplane speed	160 Gbps
Data rate	288 Gbps
Throughput	214 Mpps (wire speed)
40GBASE quad small form-factor pluggable plus transceiver (QSFP+) port densities	2
100GBASE C form-factor pluggable transceiver (CFP) port densities	N/A
Resiliency	Redundant, field-replaceable power supplies Redundant trunk groups that provide port redundancy and simplify switch configuration
Operating system	Junos OS
Traffic monitoring	sFlow
Quality-of-service (QoS) queues/port	8 unicast/4 multicast
MAC addresses	32,000
Jumbo frames	9216 bytes
IPv4 unicast/multicast routes	36,000/4,000
IPv6 unicast/multicast routes	18,000/2,000
Number of VLANs	4,096
ARP entries	16,000
